Hello,
I use Capella 7.0.1 and filtering addon
In a PAB diagram I want to filter my diagram based on filtering result.
And I want to applied filters on different kinds of objects: physical nodes, physical ports, physical links, behavioral component, component port, component exchanges and exchange items
I have one difficulty regarding filtering applied on exchange items
Do you know if it’s a “real” issue or something from my modeling?
1) Description of model
At first, I have filtering model with filtering criterions (for exemple “filtering criterion 1”, “filtering criterion 2”) and basic filtering results (for example “filtering result 1”, “filtering result 2”) based on previous filtering criterion (no composed filtering result)
In a CDB diagram I can represent my exchange items, and for each I’ve filtering criterion applied
2) Filtering result on CDB diagram:
The use of filtering result on CDB diagrams work well and allows to show exchange items accord filtering criterion applied
3) Filtering view result on PAB diagram:
The use of filtering result on PAB diagrams seem to not work for exchange items (but work for physical nodes…). Here my attempt was to see only 2 exchange items
